    150 Watt 110V 500KG DKC500DC Automatic Door Openers

    Ask Lasest Price
    Brand Name : SONGRUI
    Model Number : DKC500DC
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10000 Set/Sets per Month
    Delivery Time : 5-8 WORK DAYS
    • Product Details
    • Company Profile

    150 Watt 110V 500KG DKC500DC Automatic Door Openers


    DC Motor Automatic Gate Opener for 500kg Sliding Gate DKC500DC


    The DKC500DC gate opener designed for residential use, weight up to 500Kg and operating distance up to 8 meters.

    Compact structure, novel appearance, easy installation.


    Main Features:

    • DC 24V motor or AC motor with built-in control unit.
    • Optional connect backup battery. (DC motor)
    • Solar system compatible. (DC motor)
    • Keypad / single button interface.
    • Alarm lamp, photo beam & safety beam interface.
    • User can select auto-close function.
    • Soft start and slow stop. (Smart version)
    • Auto-reverse function when hitting obstacle during closing. (Smart version)
    • Manual key release design for emergency purposes.

    Standard unit:

    • Gate motor
    • Control board & box
    • 2pcs remote controls
    • Manual release key
    • User manual
    • Bolts & nuts

    Main technical parameters:

    Unit ModelDKC500DC
    Power SupplyAC220V/50Hz
    Maximum Gate Weight500kg
    Motor PowerDC24V/150
    Output Torque14N.m
    Output Shaft Height46mm
    Limit Switchmagnetic limit switch or spring limit switch
    Gate Moving Speed11-13m/min
    Remote Control Range≥30md
    Recording of Up Remotes25
    Frequency433.92MHz
    Work DutyS2 20min
    Noise≤56db
    Working Tempreature-20℃~+50℃
    Backup BatteryOptional
    Driving ModeGear
    Package Weight11kg

    150 Watt 110V 500KG DKC500DC Automatic Door Openers150 Watt 110V 500KG DKC500DC Automatic Door Openers150 Watt 110V 500KG DKC500DC Automatic Door Openers
