    Solar Powered 24V DC Electric Swing Gate Motor

    Ask Lasest Price
    Brand Name : SONGRUI
    Model Number : PK350DC
    Certification : CE
    Price : Negotiable
    Payment Terms : T/T
    Supply Ability : 10000 Set/Sets per Month
    Delivery Time : 5-8 WORK DAYS
    • Product Details
    • Company Profile

    Solar Powered 24V DC Electric Swing Gate Motor


    Solar Powered 24V DC Electric Swing Gate Motor

    Wifi remote automatic control DC swing gate opener electic gate motor operator. The PK350DC gate opener designed for residential courtyard swing gate use, gate leaf weight up to 300 Kg and width up to 3.0 m.The back-up battery and solar panel can be equipped with this flat door motor


    Product features:

    1. Soft start slow stop, automatic close, obstacle detection by automatic reversng.

    2. Interface for GSM, infrared sensor, alarm light, wall button.

    3. Back up battery is available.

    4. Works with solar panel.

    5. Shell material is aluminum, arm is stainless steel.

    6. Separate control unit, easy to install.


    Main technical parameters:

    Type

    PK350DC

    Driving method

    Screw driven piston type

    Operating voltage

    DC 24V for normal speed

    Max. output power

    70W per driver

    Max. piston stroke

    30 cm

    Max. piston speed

    1.5 cm / sec

    Operating cycle

    18 seconds per 90 (approx)

    Max. single - leaft weight

    300 kg per wing

    Max. single - leaft length

    3 m

    DSPS device

    Electronic timing tracker

    Gearbox

    Worm gear

    Safety clutch

    Electronic current sensing

    Limit switch

    Without

    Back up battery

    24V (4.5AH or 7 AH) (optional)

    Satery barrier

    Infared sensor (optional)

    Mian supply

    110V / 220V , 60 Hz / 50 Hz

    Electronic controller

    Microcompeter based

    Remote controller

    UHF Digital PWM type

    Temperature

    -20 ~ + 50 centi degree

    Protection Class

    IP54


    Our service:

    Welcome OEM&ODM orders

    1. Logo printing on products;
    2. Customized color box or carton;
    3. Any your ideas on products we can help you to design and put it into production.
